2 kg ABC Type Modular Fire Extinguisher

Specifications

Type

Automatic modular (ceiling mounted)

Extinguishing Media

ABC Dry Powder (MAP)

Activation Temp

~68°C (glass bulb)

Working Pressure

7–15 bar

Discharge Time

15–20 seconds

Coverage Area

~1 to 8 m² (depends on height & model)

Class A

Solid (wood, paper)

Class B

Liquid (petrol, diesel)

Class C

Electrical fires

Capacity

2 kg

Size

~ (25 × 25 × 30 cm)

Weight

~ 3.5–5 kg

Use

Electrical & enclosed area protection

Key features

• 2 KG ABC Modular Type Fire Extinguisher (Automatic)
• Suitable for Class A, B, C & Electrical fires
• Filled with ABC Dry Chemical Powder (MAP based)
• Ceiling-mounted automatic system
• Activates at preset temperature (~68°C)
• Covers approx. 1–1.5 m² area
• Provides 360° discharge coverage
• No manual operation required
• Ideal for electrical panels, server racks, control panels
• Compact, lightweight & low maintenance
• Electrical panels / control rooms
• Server rooms / UPS rooms
• Warehouses
• Vehicles / engine compartments
• Small enclosed spaces
• ✔ Automatic operation (no human needed)
• ✔ Ceiling / wall mounted
• ✔ Compact & lightweight
• ✔ Low maintenance
• ✔ Suitable for continuous protection
